• Max. input voltage: 1100 V
• Rated Input voltage: 600 V
• MPPT voltage range: 180-1000 V
• Max. input current: 10*32 A
• MPPT number: 10
• Max. input strings number: 20
• Rated output power: 110 kW
• Rated grid voltage: 3/N/PE, 220 V/380 V, 230 V/400 V
• Rated grid frequency: 50 Hz / 60 Hz
• Rated grid output current: 167.1 A / 158.8 A
• THDi: <3%, low harmonic distortion against grid
• Max. Efficiency: 98.7%
• Dimensions (W*H*D): 1065*567*344.5 mm
• Weight: 91 kg
• Operating ambient temperature range:

-25~+60°C

• Intelligent redundant fan-cooling Cooling concept
• Intelligent string monitoring, smart I-V curve scan
• IP66 Ingress protection
• Power line communication (PLC) (optional)
• Overvoltage load reduction and leakage current suppression technology, low failure rate
