• Transformerless
• Recommended max. PV power: 7.5 kW
• Max. input voltage: 600 V
• Rated Input voltage: 330V
• MPP voltage range: 90-520 V
• Max. input current: 14 A / 14 A
• MPPT number: 2
• Max. input strings number: 2
• Rated output power: 5 kW
• Rated grid voltage: 1/N/PE, 220 V / 230 V
• Rated grid frequency: 50 Hz / 60 Hz
• Rated grid output current: 22.7 A / 21.7 A
• THDi: <3%, low harmonic distortion against grid
• Max. Efficiency: 97.7%
• Dimensions (W*H*D): 310*543*160 mm
• Weight: 12 kg
• Operating ambient temperature range:

-25~+60°C

• Integrated Export Power Manager(EPM)
• Super high frequency switching technology
• WiFi/GPRS Real time monitoring
• AFCI protection, proactively reduces fire risk
